Docker Pull Timeout
Unfortunately, docker hub has been banned in mainland China due to some reasons. So many docker register proxy website were stopped, and the docker pull command output is here, when you use docker pull.
$ sudo docker run hello-world
Unable to find image 'hello-world:latest' locally
docker: Error response from daemon: Get "https://registry-1.docker.io/v2/": net/http: request canceled while waiting
for connection (Client.Timeout exceeded while awaiting headers).
See 'docker run --help'.
I try to use the LAN proxy, it doesn’t work, so i think the best way is to deploy mihomo in TUN mode on my development machine, maybe use Docker Images Proxy, but i don’t want to use it.
Simple Usage
Download the latest Mihomo release package using Github Proxy and move it to /usr/local/bin/mihomo.
curl -O -L https://gh.llkk.cc/https://github.com/MetaCubeX/mihomo/releases/download/v1.18.9/mihomo-linux-arm64-v1.18.9.gz
gunzip mihomo-linux-arm64-v1.18.9.gz
sudo mv mihomo-linux-arm64-v1.18.9 /usr/local/bin/mihomo
sudo chmod +x /usr/local/bin/mihomo
Download your Mihomo configuration to /etc/mihomo/config.yaml.
sudo mkdir -p /etc/mihomo
sudo curl -o /etc/mihomo/config.yaml https://sub.reajason.eu.org/clash.yaml
Create a systemd configuration file /etc/systemd/system/mihomo.service.
sudo vim /etc/systemd/system/mihomo.service
[Unit]
Description=mihomo Daemon, Another Clash Kernel
After=network.target NetworkManager.service systemd-networkd.service iwd.service
[Service]
Type=simple
LimitNPROC=500
LimitNOFILE=1000000
CapabilityBoundingSet=CAP_NET_ADMIN CAP_NET_RAW CAP_NET_BIND_SERVICE CAP_SYS_TIME CAP_SYS_PTRACE CAP_DAC_READ_SEARCH CAP_DAC_OVERRIDE
AmbientCapabilities=CAP_NET_ADMIN CAP_NET_RAW CAP_NET_BIND_SERVICE CAP_SYS_TIME CAP_SYS_PTRACE CAP_DAC_READ_SEARCH CAP_DAC_OVERRIDE
Restart=always
ExecStartPre=/usr/bin/sleep 1s
ExecStart=/usr/local/bin/mihomo -d /etc/mihomo
ExecReload=/bin/kill -HUP $MAINPID
[Install]
WantedBy=multi-user.target
Start the mihomo service using systemctl.
sudo systemctl daemon-reload # Reload systemd
sudo systemctl enable mihomo # Start when start up
sudo systemctl start mihomo # Start Mihomo
# Other systemctl command
# If you change the config.yaml, use this command to reload config
sudo systemctl reload mihomo
# Show the status of Mihomo
sudo systemctl status mihomo
# Show the running logs of Mihomo
sudo journalctl -u mihomo -o cat -f
Edit /etc/sysctl.conf to allow ipv4 and ipv6 forward, and open the following switch.
sudo vim /etc/sysctl.conf
# Uncomment the next line to enable packet forwarding for IPv4
net.ipv4.ip_forward=1
# Uncomment the next line to enable packet forwarding for IPv6
# Enabling this option disables Stateless Address Autoconfiguration
# based on Router Advertisements for this host
net.ipv6.conf.all.forwarding=1
If the edit was successful, use the reboot command to reboot your system.
Then use curl to check the mihomo proxy. (if you run systemctl enable mihomo, the computer will start mihomo on startup)
curl -v https://www.google.com
sudo docker pull hello-world
Tips
TUN
System proxy does not work for docker pull, but tun mode does, here is my tun mode config. Check the sub link for my entir mihomo configuration.
tun:
enable: true
stack: mixed
strict_route: true
auto-route: true
auto-redirect: true
auto-detect-interface: true
dns-hijack:
- any:53
- tcp://any:53
dns:
enable: true
prefer-h3: true
ipv6: true
listen: 0.0.0.0:53
fake-ip-range: 198.18.0.1/16
enhanced-mode: fake-ip
fake-ip-filter: [ 'rule-set:fakeip-filter,private,cn' ]
nameserver:
- https://doh.pub/dns-query
- https://dns.alidns.com/dns-query
External Control
Maybe you can consider using metacube to control your mihomo runtime config. Open the external control by adding follow config to your mihomo config.
The entrypoint is http://127.0.0.1:9090/ui.
external-controller: 127.0.0.1:9090
external-ui: ui
external-ui-url: https://github.com/MetaCubeX/metacubexd/archive/refs/heads/gh-pages.zip
If you want to use public ip, use follow config, make sure to use secret to protect your mihomo.
The entrypoint is http://publicip:9090/ui.
external-controller: 0.0.0.0:9090
secret: "generateLZQ*HRSP$kC4Nlpu"
external-ui: ui
external-ui-url: https://github.com/MetaCubeX/metacubexd/archive/refs/heads/gh-pages.zip
See the official tutorial docs for other config of external control configurations.
Diagnostic
It’s possible that your mihomo service is not running as expected or maybe your proxy is not working, set the log level to debug and check the running logs.
log-level: debug
Reload and check the runing log.
sudo systemctl reload mihomo
sudo jornalctl -u mihomo -o cat -f
